DR6000 EMC FFT Analyser – Conducted & Radiated Measurements to 6GHz

Description

Pre-compliance EMC testing shouldn’t mean booking weeks out at an external lab. The DR6000 brings full conducted and radiated emissions measurement for the 9kHz to 6GHz range in-house, in a single compact unit. FFT-based signal processing means faster scans, faster design iteration, and faster routes to compliance.

When used with the RF9xx range of pre-selectors, accurate measurements are obtained even with broadband conducted emissions.

Entirely controlled from an intuitive Windows software package, the analyser can enable a self-test and self-certification strategy to be adopted with confidence.

The PC software allows results to be printed or saved and used in other applications for reporting purposes. A full range of compatible accessories is available, including compact test cells and antennas, all fully calibrated to 6GHz.

• FFT dramatically reduces measurement time and provides rapid design iteration during pre‑compliance testing
• 9kHz—6GHz range to cover EN, FCC and international standards.
• Powerful PC software control and automation included.
• USB 3.0 interface for very simple operation.
• Windows 11 compatible (16GB RAM minimum.)
• Compact and simple to use whilst including all the necessary features for self-testing your own products.
• Made in Britain.
